Indoor Rental P4.81 LED Display Cabinet Die Casting Aluminum
500mm*500mm
Advantages
1. Indoor rental P4.81 is the most popular led screen in the
market, with high definition and high resolution
gain a good visial indoor to audience, people who see it will
shocked by this amazing viewing experience;
2. Applied with die-casting aluminum cabinet, very strong and easy
to installation, saving time and labor,
cabinet size are 500*500mm& 500*1000mm, easy to calculate the area
of led video wall, and maintence simple.
Specification
Item | Specification |
Pixel Pitch | 4.81mm |
Module Resolution | W52×H52dots |
Module Size | 250*250mm |
Led Packing | 2121 |
IP Rate | 65 |
IC | Constant current IC |
LED composition | 1R1G1B |
Cabinet Size | 1000*500mm |
Module Qty | W4X H2 =8PCS |
Physical Resolution | W202×H104dots |
Power Consumption(MAX.) | 200 W/m² |
Power Consumption(AVE.) | 100 W/m² |
Cabinet Material | Die-casting Aluminum |
Physical Density | 43222 dots/m² |
Net Weight | 6.1Kg |
Brightness | 900cd/m² |
Colors | 16.7 trillion |
Brightness Control | Software 256 level adjustable |
Gray Level | 14 |
View Distance | 5～30m |
Refresh Rate | 1920Hz |
Drive Mode | 1/13s |
Life Span | 100,000h |
MTBF | 1000h |
Control mode | Synchronous control or Asynchronous control |
Frame Frequency | ≥60Hz |
Certification | CE/ROHS/FCC/CCC/ISO9001/ISO14001 |
Operation Temperature | -20℃ ～ +45℃ |
Operation Humidity | 10%～95% |
How to measure brightness?
Nit is a unit to measure luminance over a square meter. It is also
well-known as meter-lamberts.
NIT = meter-lamberts = candela per square meter (cd/m²) .
Why does brightness matter?
At night, generally speaking, LED displays are always readable and
working fine.
How to make a good choice between the flight case and wooden case?
Flight case is usually used for the rental LED display, which makes
the transportation more convenient and
protect the LED display better.
Wooden case is only for one time using transportation, such as the
fixed installation LED display, wooden case
is the best way for packing since the low cost and at the same time
it can also ensure the safety of the LED display.
If your LED display screen system is for the rental use, please
choose the flight case.
What is best viewing distance? How to calculate the best viewing
distance of the LED display?
Best viewing distance refers to the distance between the LED
Display and its viewers, where the people can see a
whole and clear picture of the image on the LED display.
There are 2 ways to calculate the best viewing distance: one is by
the pixel pitch, one is by the diagonal.
