P6 Full Color Outdoor Led Video Walls LED Sign Panel Screen Commercial Advertising Display

Shenzhen Longdaled Co.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap P6 Full Color Outdoor Led Video Walls LED Sign Panel Screen Commercial Advertising Display from wholesalers

    Buy cheap P6 Full Color Outdoor Led Video Walls LED Sign Panel Screen Commercial Advertising Display from wholesalers
    • Buy cheap P6 Full Color Outdoor Led Video Walls LED Sign Panel Screen Commercial Advertising Display from wholesalers

    P6 Full Color Outdoor Led Video Walls LED Sign Panel Screen Commercial Advertising Display

    Ask Lasest Price
    Brand Name : Longda LED
    Model Number : Outdoor P6
    Certification : CE / ROHS / CCC / FCC / ISO9001 / ISO14001
    Price : Usd799 ~ Usd999 / Sqm ( Price is negotiable )
    Payment Terms : L / C , T / T , Western Union , MoneyGram
    Supply Ability : 5000sqm per month
    Delivery Time : 15 - 18 days
    • Product Details
    • Company Profile

    P6 Full Color Outdoor Led Video Walls LED Sign Panel Screen Commercial Advertising Display

    Outdoor Led Video Walls P6 Outdoor Full Color LED Sign Panel Screen Commercial Advertising Display


    Specifications :


    Outdoor P6 LED Screen

    Part I Technicial Parameters

    Led Module Specification

    NO.

    Item

    Specification

    1

    Pixel Pitch

    6mm

    2

    Module Resolution

    W32×H32dots

    3

    Module Size

    192*192mm

    4

    Led Packing

    3535

    3528

    5

    IP Rate

    65

    6

    IC

    Constant current IC

    5124

    7

    LED composition

    1R1G1B

    Cabinet Specification

    1

    Cabinet Size

    576*576mm

    960*960mm

    2

    Module Qty

    W3X H3 =9PCS

    W5X H5 =25PCS

    3

    Physical Resolution

    W96×H96dots

    W160×H160dots

    4

    Power Consumption(MAX.)

    600 W/m2

    5

    Power Consumption(AVE.)

    230 W/m2

    300 W/m2

    6

    Cabinet Material

    Die-casting Aluminum

    7

    Physical Density

    27777 dots/m2

    8

    Net Weight

    7.5Kg

    7.7Kg

    Screen Specification

    1

    Brightness

    5500cd/m2

    1000cd/m2

    2

    Colors

    16.7 trillion

    3

    Brightness Control

    Software 256 level adjustable

    4

    Gray Level

    14

    5

    View Distance

    6~50m

    6~150m

    6

    Refresh Rate

    ≥1200~1920Hz

    ≥960Hz

    7

    Drive Mode

    1/8s

    1/16s

    8

    Life Span

    100,000h

    9

    MTBF

    1000h

    10

    Control mode

    Synchronous control or Asynchronous control

    11

    Frame Frequency

    ≥60Hz

    12

    Certification

    CE/ROHS/FCC/CCC/ISO9001/ISO14001

    13

    Operation Temperature

    -20℃ ~ +45℃

    14

    Operation Humidity

    10%~95%


    * High brightness & High refresh rate.
    * Nova star/Linsn/Colorlight control system indoor outdoor led screen


    Rear and Front Maintenance
    1. Rear service, using keys to open the door to maintenance, quickly and convenient, and save cost for installation and maintenance.
    2. Front service, the best solution for fixed installation, using full front service to remove any faulty parts from the front of the LED cabinet. Module with mechanical lock support both front and rear service.

    P6 Full Color Outdoor Led Video Walls LED Sign Panel Screen Commercial Advertising Display


    FAQ :


    Question 1: How can I trust your LONGDA LED factory ?


    Answer : Yes, when you talk with us now , we are here . We do led since 2009 ,it is over 12 years . In the past 8 years , we develop so well. Tomorrow and future , we will largely expand our LED market, you will see it .
    Welcome to try our LED sample quality .
    We do have100% confidence in our LED product .


    Quesiton 2: If I need led very urgently ,how fast can you finish the goods ?


    Answer:How fast you want ?Three days ?One week ? Definite shipping date ?
    We produce LED everyday .We have some led modules in stock .
    Put the most urgent and important order at the first place .
    You are important to us .Surely to establish first-time good relationship .
    We do must finish it at FAST ROCKET TIME.


    Q3:Is it easy to install this led display ?


    Answer : If you are new to LED ,we will help you to know led from ZERO to Professional .
    We have installation manual book and professional engineering team to guide you .
    To help you better understand LED is to make us get your earlier trust .
    If you knew LED before,we can learn from each other.
    We could be Future Shaking-hands Partners .
    Our engineering team remote help is ready for you 24-hours .
